规格表
适用管外径 | 钢带宽 | 带胶厚度 | 钢片厚度 | 螺丝孔径 | 包装数量 |
6mm | 15mm | 4mm | 0.6mm | 6mm | 200 |
8mm | 15mm | 4mm | 0.6mm | 6mm | 200 |
10mm | 15mm | 4mm | 0.6mm | 6mm | 200 |
12mm | 15mm | 4mm | 0.6mm | 6mm | 200 |
14mm | 15mm | 4mm | 0.6mm | 6mm | 200 |
16mm | 15mm | 4mm | 0.6mm | 6mm | 100 |
18mm | 15mm | 4mm | 0.6mm | 6mm | 100 |
20mm | 15mm | 4mm | 0.6mm | 6mm | 100 |
22mm | 15mm | 4mm | 0.6mm | 6mm | 100 |
24mm | 15mm | 4mm | 0.6mm | 6mm | 100 |
25mm | 15mm | 4mm | 0.6mm | 6mm | 100 |
28mm | 15mm | 4mm | 0.6mm | 6mm | 100 |
30mm | 15mm | 4mm | 0.6mm | 6mm | 100 |
32mm | 15mm | 4mm | 0.6mm | 6mm | 100 |
34mm | 15mm | 4mm | 0.6mm | 6mm | 100 |
36mm | 15mm | 4mm | 0.6mm | 6mm | 100 |
38mm | 15mm | 4mm | 0.6mm | 6mm | 100 |
40mm | 15mm | 4mm | 0.6mm | 6mm | 50 |
42mm | 15mm | 4mm | 0.6mm | 6mm | 50 |
44mm | 15mm | 4mm | 0.6mm | 6mm | 50 |
46mm | 15mm | 4mm | 0.6mm | 6mm | 50 |
48mm | 15mm | 4mm | 0.6mm | 6mm | 50 |
50mm | 15mm | 4mm | 0.6mm | 6mm | 50 |
注：以上为常规型号，特殊规格和要求可来样定制,手工测量，数据有一定误差.
